HGP Series Helical High-Pressure Gear Pumps for Aerial Work Platforms

Name: HGP Series Helical High-Pressure Gear Pumps for Aerial Work Platforms
Brand: We are MEISON, the international sales department of Dongxu Hydra
SKU: HGP Series
Price: 300 USD
Availability: InStock

Product description
Design: External helical gear pump
Pump body material: High-strength die-cast aluminum alloy
End cover material: Cast iron
Maximum speed: 3000 r/min (recommended 1500–2000 r/min)
Fluid viscosity: 15–100 cSt (recommended anti-wear hydraulic oil 46#/68#)
Mounting Type: Flange mounting, two-hole / diamond flange
Shaft Extension Type: Flat key shaft (splined shaft available upon request)

0.0 (0 Reviews)

0 Sold

$300.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

About HGP Series Helical High-Pressure Gear Pumps
The Dongxu HGP Series helical high-pressure gear pumps feature a helical meshing design, ensuring smooth operation and low noise levels. The pump body is constructed from high-quality aluminum alloy, offering a lightweight design and rapid heat dissipation. Equipped with durable sealing components, these pumps deliver exceptional pressure resistance, with a rated pressure of up to 16 MPa and a peak pressure of 21 MPa. They offer advantages such as high efficiency, wear resistance, durability, minimal internal leakage, and easy installation. A comprehensive range of specifications is available, supporting various displacement and rotation direction options.

Key Features

Low-noise operation: Helical gear meshing provides smoother operation, resulting in noise levels 3–5 dB lower than those of straight-tooth pumps, making it ideal for noise-sensitive applications.

High-pressure performance: Rated pressure of 16–21 MPa, with peak pressure up to 25 MPa; high volumetric efficiency and insensitivity to fluid contamination.
Lightweight Construction: Aluminum alloy pump body + cast iron end caps ensure low weight and excellent heat dissipation. Comes with standard mounting flanges for strong adaptability.
Maintenance-Free and Highly Reliable: Simple structure with no wear-prone parts; oil-resistant and wear-resistant for a long service life and low maintenance costs.
Wide Range of Specifications: Three series—HGP-1A, 2A, and 3A—covering displacements from 1 to 30 mL/r, meeting small- to medium-flow requirements.

Application Scenarios

Small hydraulic stations, hydraulic power units.
Light-duty construction machinery such as forklifts, aerial work platforms, and sanitation vehicles.
Machine tool lubrication systems, light industrial automation equipment.
General-purpose hydraulic applications with noise and cost considerations.

Packaging & Delivery

Protective Industrial Packaging: Each pump is carefully packaged in reinforced, moisture-proof materials to prevent surface damage and shaft corrosion during transit.
Global Fulfillment: Factory-direct dispatch with optimized logistics support, ensuring reliable and timely delivery to international destinations.
Installation Ready: Every unit is inspected for dimensional accuracy and functional testing, ready for immediate integration into your system.

Certification & Quality Assurance

Quality Management: Manufactured under strict ISO9001 standards, ensuring consistent pressure and flow characteristics across every unit.
Operational Reliability: Built for high-cycle industrial service, serving as a reliable foundation for equipment lifespans of 10+ years.
Integrity Verification: Every gear pump undergoes rigorous high-pressure testing to ensure leak-free performance and functional reliability before leaving our factory.

The MEISON Advantage

Factory-Direct Expertise: "Factory-Direct Expertise. Professionally Curated." — 20+ years of precision mechanical manufacturing leadership.
Global Trusted Partner: Over 1,000,000 units sold to 6,000+ satisfied customers worldwide, proving MEISON’s commitment to quality.
Innovation & R&D: 60+ technical patents support our commitment to high-performance, precision-engineered hydraulic solutions.
Cinematic Industrial Image: Our designs prioritize technical precision and professional aesthetics, helping you build immediate, long-lasting trust with B2B buyers.

FAQs

（Frequently Asked Questions）

You are manufacturer or trading company?

We are a direct manufacturer, Dongxu Hydraulic Machinery Co., Ltd.
This means you get the most competitive factory price and direct technical support. There are no middlemen or traders involved. You are welcome to visit our factory at any time.

Can I have OEM service and put my logo on products or packaging?

Yes, OEM service is available. We offer customized solutions including brand logo printing, custom color painting, special thread types (G/BSPT/NPT), and SAE flange connections. Your brand identity is respected .

What is the lead time for this model?

It depends on the quantity. Shipment typically occurs within 10–15 business days after order confirmation. For large OEM orders, please contact us for confirmation.

What warranty services do you offer?

We offer a 12-month comprehensive warranty. In addition, we provide extended warranty and maintenance packages.
